MOC3012

MOC3012, optically coupled isolator, 250V, 300mW, 1A, dip

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.39~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 500 :	0.50 / Piece
500 ~ 1000 :	0.45 / Piece
1000 ~ 1500 :	0.39 / Piece

PartNumber:: MOC3012

Brand:: Fairchild Optoelectronics Group - Fairchild | D/C: 04+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-04

From Other Seller

Part Number:MOC3012
US $0.39 - 0.50
Quantity:

piece

Product Summary

The MOC3012 is an optically coupled isolator consisting of a Gallium Arsenide infrared emitting diode coupled with a light activated silicon bilateral switch performing the functions of a triac mounted in a standard 6 pin dual-in-line package. It is ideal for: (1)CRTs; (2)Power Triac Driver; (3)Motors; (4)Consumer appliances; (5)Printers.

Parametrics

MOC3012 absolute maximum ratings: (1)storage temperature: -550c - +1500c; (2)operating temperature: -400c - +1000c; (3)Forward Current: 50mA; (4)Reverse Voltage: 6V; (5)Power Dissipation: 70mW; (6)Off-State Output Terminal Voltage: 250V; (7)Forward Current (Peak): 1A; (8)Power Dissipation: 300mW.

Features

MOC3012 features: (1)options :- 10mm lead spread - add g after part no. surface mount - add sm after part no. tape&ree- add smt&r after part no.; (2)high isolation voltage (5.3kvrms ,7.5kvpk ); (3)250v peak blocking voltage; (4)alelectricaparameters 100% tested; (5)custom electricaselections available.
